XC-62 COMPACT DMX DIMMER
Version 0.2 OWNERS MANUAL 03/08/2011
www.lightronics.com 20070913 drp
Lightronics Inc. 509 Central Drive Virginia Beach, VA 234354 757 486 3588
CONTROL SOURCE SELECTION (CnFG)
The CnFG menu selects what source will control the
dimmer pack. The 6 choices are:
1. Normal wired DMX ( 5Pin )
2. Stand alone chase ( chAS )
3. Local ( LocL )
4. Architectural Station ( Arch )
5. RS485 ( r485 )
6. Wireless DMX ( Antd )
DMX:
When selected, the dimmer pack responds to
USITT DMX-512 signals received on the male 5 pin
XLR connector in one end of the unit. The female 5
pin XLR connector is used to pass the DMX signal on
to another DMX dimmer pack.
STAND ALONE CHASE: This menu enables chaser
operation. The dimmer will ignore other signal
sources when chaser operation is active.
LOCAL: Local control enables you to operate the
XC-62 channels manually without an external
controller. You can set a static scene and leave the
unit as is. This may be useful for a store display or
other situation where a continuous lighting scene is
needed. The dimmer will IGNORE OTHER
CONTROL SIGNAL SOURCES when local
operation is active.
See the section for CHANNEL TEST for more about
operating channels locally.
ARCH: Operation from Lightronics architectural
smart remote stations is not currently available.
RS-485: Operation from RS-485 devices is not
currently available.
WIRELESS DMX:
The XC-62 wireless option allows
the unit to be run from a console or other controller
which transmits DMX over a wireless link.
SELECTING A CONTROL SOURCE
Hold MENU/NEXT for aprox. 5 seconds to access
the menus. The display will show
dSET .
Push MENU/NEXT until the display shows
SYSt .
Push SELECT. The display will toggle between
CnFG and the currently selected control source.
Use to select the desired source. Push
SELECT to save the change.
Push MENU/NEXT to advance to the next system
setup menu display.
OTHER SYSTEM SUB MENUS
The wireless logoff menu (
Log- ) will function only
if the optional wireless hardware is installed in the
XC-62. Otherwise it is ignored.
The remaining sub menus
ScEn, ArcU , and
Puur (power type) are associated with features
which are not currently available. Some of these
settings can be changed within the menus but the
changes will be ignored.
C n F G 5 P i n
