MAIN FEATURES....................................................................................................................................2
WARRANTY REGISTRATION..................................................................................................................2
SAFETY PRECAUTIONS........................................................................................................................3
ELECTRICAL PRECAUTIONS................................................................................................................4
SAFETY PRECAUTIONS........................................................................................................................5
UNPACKING...............................................................................................................................6
INTRODUCTION....................................................................................................................................6
SET-UP PRECAUTIONS.........................................................................................................................6
QUICK START.........................................................................................................................................7
FUNCTIONS AND CONTROLS
FRONT PANEL............................................................................................................................8
REAR PANEL............................................................................................................................10
TYPICAL SET-UP DIAGRAMS...............................................................................................................11
CLEANING......................................................................................................................14
CROSS FADER REPLACEMENT..........................................................................................................14
WARRANTY.........................................................................................................................................15
SPECIFICATIONS.......................................................................................................................16
Q-D1™ CONTENTS
Q-D1™ MAIN FEATURES
• Fader “Q” Start • Independent Gains Per Channel
• Q-Start Compatible (for use with compatible • Front Access Headphone Jack
(American Audio CD Players ) • Low Residue Resistance Crossfader
• Equipped with high quality Crossfader • 2 Band EQ per channel
(Replaceable) • 2 Phono, & 2 Line Level Inputs
• High output to headphones • Two Turntable Ground Prongs
• Cue Mixing • Front Access 1/4” Mic Jack
• Extremely clean signal to noise ratio • Record Out
• Power Switch
The Q-D1™ carries a one year limited warranty. Please fill out the enclosed warranty card to validate
your purchase. All returned service items whether under warranty or not, must be freight pre-paid
and accompany a return authorization (R.A.) number. The R.A. number must be clearly written on the
outside of the return package. A brief description of the problem as well as the R.A. number must
also be written down on a piece of paper and included in the shipping container. If the unit is under
warranty, you must provide a copy of your proof of purchase invoice. You may obtain a R.A. number
by contacting customer support at (800) 322-6337.
Q-D1™ WARRANTY REGISTRATION
Please Note: Specifications and improvements in the design of this unit and this manual are subject
to change without any prior written or published notice.
For service parts visit http://parts.americandj.com
