LN-PRS40M PREMIUM NIGHT VISION RIFLESCOPE
Glossary:
1 – Ocular Focusing Wheel
2 – Distance Focusing Wheel
3 – Power and Reticle Illumination Switch
4 – Battery Compartment Cover
5 – Battery Cover Fixing Screw
6 – IR Illuminator Switch
7 – IR Illuminator
8 – Weapon Mounting Screws
9 – Objective Lens Cover with Daylight Filter
10 – Vertical and Horizontal Adjustments
11 – Accessory Mounting Plate
