a) You may need to repeat the process of rotating the ocular
focusing wheel (7) and distance focusing wheel (1) several
times until you get a good feel of it
b) You may be viewing an object that it too close – the
minimum focusing distance is approximately 10m or 33 ft
c) You may have dirty objective or ocular lens – you may clean
them with soft lens cleaning cloth
3.
There are black dots (specs) in the field of view:
THIS IS NORMAL – BLACK DOTS ARE MICROSCOPIC
PARTICLES INSIDE THE TUBE AND RESULT FROM THE
TUBE MANUFACTURING PROCESS, WHICH IS NEVER
COMPLETELY SPEC-FREE
IMPORTANT INFORMATION: NEVER:
1. Intentionally turn on the unit without protective lens cover during
daylight or in a well-lit area (when operating in Night Mode)
2. Allow direct projecting light into the objective lens (automobile
headlights, flashlight beams, laser beams) (when operating in
Night Mode)
3. Try to disassemble the unit by yourself or by anyone who is not
our authorized technician. Doing so may result in injury and will
void any warranty claims
4. Leave the battery inside the unit for a long period of time – the
battery may overheat and leak, which will render the unit
inoperable and will void the warranty
5. Submerse the unit into water
TECHNICAL SPECIFICATIONS: NIGHT DAY
Image Magnification____
3x
6x
Field Of View__________
9°
4.5°
Shooting Range______ 350m (1,141ft) at ¼Moon
Focusing Distance_____
10m (33ft) - ∞
Objective Lens________
f1.5/80mm
f1.5/160mm
Power______________
1x3V Lithium
Operation time_______
55hrs
Dimensions, mm_____ 305x92x85
350x80x85
Weight, g___________
1200g
900g
WARRANTY INFORMATION:
Your day/night vision riflescope is guaranteed to be free of manufacturing
defects for a period of two (2) years from the date of purchase. One
exception is the Intensifier Tube, which is guaranteed for one (1) year.
Please refer to the enclosed warranty card for complete warranty details.
---------------------------------------------------------------------
LUNA OPTICS, INC. 54 Columbus Ave., Staten Island, NY 10304 (USA)
Tel: +1-718-556-5862; Fax: +1-718-556-5869;
© 2012
