Receiver rear panel – Lectrosonics SR175 User Manual
Page 4

RECEIVER REAR PANEL
ANT terminal - A standard BNC connector compatible with the supplied antenna.
12 VDC IN - Connect the power supply here - the CH-12 AC adapter is supplied with the receiver for
powering the unit from a 110V AC source. The receiver may also be powered from 12 volt DC sources
using the correct plug (Switchcraft S-760 power plug); the center pin on the receiver jack is positive (+).
AUDIO OUT (standard XLR jack) - This is the audio output that should connect into your sound system.
Being such a common type of connector, many different adapters and cords are available from local
audio or electronics dealers in your area, or from the factory. The pin configuration is:
Pin 1 - shield
Pin 2 - Audio (+)
Pin 3 - Audio (-)
ANT
12V DC
IN
AUDIO OUT
1
2
3
Figure 2 - SR175 Rear Panel
3
