TROUBLESHOOTING
Before going through the following chart, be sure that you have a good battery in the transmitter. It is important that
you follow these steps in the sequence listed.
SYMPTOM
POSSIBLE CAUSE
TRANSMITTER BATTERY LED OFF
1) Battery is inserted backwards.
2) Battery is dead.
RECEIVER CODE LAMP OFF
1) Transmitter not turned on.
2) Transmitter battery is dead.
3) Receiver antenna missing or improperly positioned.
4) Transmitter and receiver not on same frequency. Check
labels on transmitter and receiver.
5) Transmitter and receiver do not have the same internal
code. Check labels on transmitter and receiver.
5) Operating range is too great.
NO SOUND BUT RECEIVER MOD
LEVEL LEDs ARE ON
1) Receiver audio output is disconnected or cable is
defective or mis-wired.
2) Sound system or recorder input is turned down.
DISTORTED SOUND
1) Transmitter gain (MIC LEVEL) is too high. Speak or
sing into the transmitter and check mod level lamps
on the receiver.
2) Receiver output may be mis-matched with the sound
system or recorder input.
3) Excessive wind noise or breath “pops.” Use windscreen
or re-position the microphone.
HISS AND NOISE - AUDIBLE DROPOUTS
1) Transmitter gain (MIC LEVEL) too low.
2) Receiver antenna missing or obstructed.
3) Operating range too great.
EXCESSIVE FEEDBACK
1) Transmitter gain (audio level) too high. Check gain
adjustment and/or reduce receiver output.
2) Microphone too close to speaker system.
3) Microphone too far from the user’s mouth.
REPLACEMENT PARTS and ACCESSORIES
Part No.
Description
CH-12
110 Volt AC adapter for receiver
A-185BNC
Telescoping, swivel-mount antenna with BNC plug
A-185COAX
Remote folded dipole coaxial antenna for VHF receivers
A-170AC
Straight whip antenna with BNC plug
A-200
Dipole antenna with dual whips & aluminum base
M119-MICRO
Lavalier microphone, omni-directional pattern
M140-MICRO
Lavalier microphone, cardioid pattern
M150-MICRO
Lavalier microphone, omni-directional pattern with added high
frequency response
