AIP-00055 Rev. C – 09/06 Page 2/5
AL-CAT5EW Connection Diagram
Terminal Strip*
To Ground
Terminal Strip*
CAT5e Cables
(Unterminated)
LINE SIDE EQUIPMENT SIDE
*Unit provides protection
to both sides equally.
