page 9
(5) 3-Position Switch
left position:OFF - Middle position:STANDBY - Right position:ON
In the “STANDBY” position, the audio is muted.
(6) LED Indicator
Red when the switch is in “STANDBY” position - Green in “ON” position.
(7) Audio Output Connector
This 3.5mm mono connector is where the mic is plugged in. This connec-
tor was designed to be used with a special “screw-down” connecting jack
that eliminates the possibility of the jack being accidentally pulled out. A
standard 3.5mm mono jack can also be used but will not afford the extra
protection.
(8) Metal Belt Clip
Used to attach the 32BT securely to a belt.
NOTE: Remove the battery if the transmitter is not used for a long period of time.
Electrical energy can perform many useful functions. But
improper use can result in potential electrical shock or
fire hazards. This product has been engineered and
manufactured to assure your personal safety. In order
not to defeat the built-in safeguards, observe the follow-
ing basic rules for its installation, use and servicing.
ATTENTION:
Follow and obey all warnings and instructions marked
on your speaker and its operating instructions. For safety,
please read all the safety and operating instructions be-
fore you operate this speaker and keep this booklet for
future reference.
INSTALLATION
1. Polarization - Your speaker equipped with a polarized
alternating current line plug (a plug having one blade
wider than the other). This plug will fit into the power
outlet only one way. This is a safety feature.
If you are unable to insert the plug fully into the out-
let, try reversing the plug. If the plug should still fail to fit,
contact your electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the polarized plug.
2. Power Sources - Operate your speaker only from the
type of power indicated at the voltage selector switch on
the rear panel. If you are not sure of the type of power
supply at your site, consult with the local power com-
pany.
3. Overloading - Do not overload wall outlets, extension
cords, or integral convenience receptacles as this can
result in a risk of fire or electrical shock.
4. Power Cord Protection - Power supply cords should be
routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying
particular attention to cords at plugs or convenience re-
ceptacles.
5. Ventilation - A metal heatsink is provided for heat dis-
sipation. To ensure reliable operation of the speaker and
to protect it from overheating, this heatsink most not be
blocked or covered. Do not place this speaker in a built-
in installation such as a bookcase or rack unless proper
ventilation is provided.
6. Wall Mounting - Mount this speaker to the wall or stand
only as recommended by the manufacturer.
USE
1. Accessories - To avoid personal injury:
•Do not place this speaker on an unstable cart, stand,
tripod, bracket, or table. It may fall, causing serious in-
jury and serious damage to the speaker.
•Use only with a cart, stand, tripod, bracket or table
recommended for this purpose or included by the manu-
facturer. When using the included bracket, follow the
manufacturer’s instructions for mounting the
speaker.
2. Wall or Ceiling Mount - The product should be
mounted to the wall or ceiling only as recommended
by the manufacturer.
3. Speaker and Cart Combinatio n - A speaker and
cart combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may
cause the speaker and cart combination to overturn.
4. Water and Moisture - Do not use this speaker near or in
water or in an extremely moist environment.
5. Cleaning - Unplug the speaker from the wall outlet be-
fore cleaning. Do not use liquid or aerosol cleaners.
Use a damp cloth for cleaning.
6. Heat - Situate the speaker away from heat sources
such as radiators, heat registers or other heat produc-
ing items.
7. Attachments - Do not use attachments not recom-
mended by the product manufacturer as they may cause
hazards.
8. Replacement Parts - When replacement parts are re-
quired, be sure the service technician has used replace-
ment parts specified by the manufacturer or have the
same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other
hazards.
9. Safety Check - Upon completion of any service or re-
pairs to this product, ask the service technician to pre-
form safety checks to determine that the product is in
proper operating condition.
10. Damage Requiring Service - Unplug this product from
the wall outlet and refer servicing to qualified service
personnel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen
into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by follow-
ing the operating instructions. Adjust only those controls
that are covered by the operating instructions as an im-
proper adjustment of other controls may result in dam-
age and will often require extensive work by a qualified
technician to restore the product to its normal operation,
e) If the product has been dropped or damaged in
any way, and
f) When the product exhibits a distinct change in per-
formance - this indicates a need for service.
A APS 25 using wall-mount bracket
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.
CAUTION:
This powered speaker should be used with either 110-125VAC / 210-
240VAC - 50Hz/60Hz only. DO NOT use any other power source.
Warning: To prevent shock hazard do not open or remove speaker/speaker grill.
(the lighting flash with arrowhead symbol within an
equilateral triangle) is intended to alert the user to the
presence of uninsulated "dangerous voltage" within
the product's enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons: and (the explanation point within an
equilateral triangle) is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature accompanying
the product.
IMPORTANT
SAFETY
INSTRUCTIONS
