Refrigerant Circuit Performance Charts (continued)
Refrigerant Circuit Performance Charts: A & B Voltage Models
Spa Condition: Water @ 104ºF & 45 GPM, Ent. Air: 80 ºF - 63% R.H.
Nominal Unit Amps
by Voltage Code
Model Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Superheat
ºF
Subcooling
ºF
Water ∆
T
ºF
A B
H/AT100”X”R 307
85
10
25
3.9 28
H/AT120”X”R (Data
Pending)
(P
en
di
ng
)
Standard Condition: Water @ 80ºF & 45 GPM, Ent. Air: 80 ºF - 63% R.H.
Nominal Unit Amps
by Voltage Code
Model Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Superheat
ºF
Subcooling
ºF
Water ∆
T
ºF
A B
H/AT100”X”R 224
81
11
20
4.0 23
H/AT120”X”R 205
74
16
18
4.6 25
(P
en
di
ng
)
Low Condition: Water @ 80ºF & 45 GPM, Ent. Air: 50 ºF - 63% R.H.
Nominal Unit Amps
by Voltage Code
Model Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Superheat
ºF
Subcooling
ºF
Water ∆
T
ºF
A B
H/AT100”X”R 218
49
8
31
2.8 22
H/AT120”X”R
212
44 9 26 3
24
(P
en
di
ng
)
High R.H. Condition: Water @ 80ºF & 45 GPM, Ent. Air: 80 ºF - 80% R.H.
Nominal Unit Amps
by Voltage Code
Model Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Superheat
ºF
Subcooling
ºF
Water ∆
T
ºF
A B
H/AT100”X”R 227
89
14
18
4.4 23
H/AT120”X”R 208
80
17
19
4.9 26
(P
en
di
ng
)
Cooling Condition: Water @ 85ºF & 45 GPM, Ent. Air: 95 ºF - 34% R.H.
Nominal Unit Amps
by Voltage Code
Model Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Superheat
ºF
Subcooling
ºF
Water ∆
T
ºF
A B
H/AT100”X”R 276
93
14
1
2.5 27
H/AT120”X”R 280
82
16
6
3 32
(
Pe
nd
ing
)
