11
BT7522
PRODUCT DIMENSIONS
THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO
LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT.
WALL PLATE
INTERFACE PLATE
45mm
1.8"
200mm
7.9"
100mm
3.9"
75mm
3"
75mm
3"
100mm
3.9"
100mm
3.9"
108mm
4.3"
175mm
6.9"
170mm
6.7"
24mm
0.9"
13.5mm
0.5"
8.5mm
0.3"
12°
20°
24mm
0.9"
R 79.2mm
(3.1")
R 70.8mm
(2.8")
78mm
3.1"
78mm
3.1"
40°
40°
125mm
4.9"
214mm
8.4"
114mm
4.5"
214mm
8.4"
114mm
4.5"
