Impulse BT7505 User Manual
Page 5
5
PLEASE KEEP THIS FOR FUTURE REFERENCE
REF
PART NAME
QTY
1 ADAPTOR
PLATE
1
2 INTERFACE
ARM
2
3 M5
METAL
WASHER
12
4
M5 x 12mm SCREW
12
INTERFACE KIT
A
M4 x 12mm SCREW
8
B
M4 x 16mm SCREW
8
C
M4 x 25mm SCREW
4
D
M4 x 40mm SCREW
8
E
M5 x 25mm SCREW
6
F
M5 x 50mm SCREW
4
G
M6 x 12mm SCREW
4
H
M6 x 25mm SCREW
4
I M5
METAL
WASHER
8
J
M5 x 12mm SPACER
8
K
M5 x 30mm SPACER
4
A
B
C
D
E
F
G
G
I
J
K
