INSTALLATION INSTRUCTIONS
i. Attach VESA mount (75 x 75mm or 100 x 100) to BT7502.
VESA mount
interface plate
2
1
ii. Attach to flat screen.
FLAT
SCREEN
1
E
D
C
B
A
3 4 5
TOP
BOTTOM
SCREENS WITH M8 FIXINGS
G
G
G
Screw parts G into the
flat screen fixing holes.
Continue with
screen mounting.
PART H FOR
USE WITH
PART A
H
