ENGLISH
28
Step 3. Replace the computer cover after securing the Adapter with a bracket
screw.
Step 4. Gently connect the 3 external antennas to the connectors on the Adapter’s
bracket.
Step 5. Power on your PC.
4. Wireless Network Utility
4.1 Introduction
After installing the driver, the Adapter provides a convenient and powerful utility that
allows you to set up, configure, and know your networking status easily and clearly.
You will see the icon( ) on the Windows task bar when you finish the installation.
Besides, the small icon will change color to reflect current wireless network connection
status. The status indicates as follow:
• : Indicate Connected and Signal Strength is Good.
• : Indicate Connected and Signal Strength is Normal.
