SWITCHERS
3
•
Any changes or modifications to the unit not
expressly approved by Altinex, Inc. could void
the user’s authority to operate the equipment.
ABOUT YOUR SWITCHER 2
The MX2214RM is a 4-in, 1-out high resolution
RGBS relay switcher designed to allow the
connection of as many as four computer video or
broadcast video sources to a single presentation
display. The MX2214RM can be controlled using its
front panel through RS-232 or through contact
closures. Contact closure control requires the use of
an optional adapter, part # RC5204CC.
The MX2214RM uses relays internally for each
channel, enabling it to pass a wide variety of low-
voltage signal types in addition to RGBS. The
MX2214RM also passes RGsB, Component Video
(Y, R-Y, B-Y), S-Video (Y/C), Composite Video,
Audio, and RS-232.
The MX2214RM can also be used bi-directionally; a
signal can be routed “backwards” through the
switcher to allow a single source to be connected to
as many as six displays.
The MX2214RM offers a 9-pin control port, which
provides a means of interconnection for RS-232 and
contact closure control, as well as other special
features. For instance, when multiple MX2214RM
units are looped together to create a larger switcher,
two pins on the 9-pin control ports can be connected
to make the switchers respond as a single unit.
Using a similar method, multiple MX2214RM units
can be made to operate in a Master-Slave mode,
with all units responding to a single button selection.
Using optional hardware, a single MX2214RM can
be rack-mounted by itself or two units can be rack-
mounted side-by-side.
TECHNICAL SPECIFICATIONS 3
FEATURES/DESCRIPTION MX2214RM
GENERAL
Inputs
4
Input Connectors Four 4-BNC Female
Outputs 1
Output Connector 4-BNC Female
Compatibility RGBS, RGsB,
Component Video (Y,
R-Y, B-Y), S-Video
(Y/C), Composite
Video, and Audio
Table 1. MX2214RM General
MECHANICAL MX2214RM
Material 0.1” Al
Finish Gray
Top Panel Lexan
Height (inches) 3.38in (86mm)
Width (inches) 8.50in (216mm)
Depth (inches) 4.38in (111mm)
Weight (pounds) 3.0lbs (1.36kg)
Ship Weight (pounds) 4.0lbs (1.82kg)
T
°
Operating 10
°
C-35
°
C
T
°
Maximum 50
°
C
Humidity 90
%
non-condensing
MTBF (calculations) 40,000 hrs
Table 2. MX2214RM Mechanical
ELECTRICAL MX2214RM
Input Video Signal
Analog Signal
+/-10V p-p max
Impedance 75 Ohms (unselected
inputs)
Input Sync Signal
Composite Sync
TTL(+/-),
Analog 0.3-1.0V
Sync on Green -0.3V
Impedance pass-through
Output Video Signals
Analog Signal
+/-10V p-p max
Fall/Rise Time (ns) 1.9
Impedance 75 Ohms (pass-
through)
Output Sync Signal
Composite Sync
TTL(+/-),
Analog 0.3-1.0V
Sync on Green -0.3V
Impedance pass-through
Frequency Compatibility
Horizontal
15-200 kHz
Vertical 30-190 Hz
Typical Video Bandwidth 400 MHz
