Control panel at a glance
How is it made?
E. Upper rack
F. Top spray arm
G. Rack height adjuster
H. Lower rack
I. Bottom spray arm J. Salt container cap
K. 4 piece filter
L. Detergent and rinse aid
dispenser
M. “Turbo dry” fan
Technical Characteristics
This dishwasher conforms
to the following Standards
for U.S.A and Canada:
• UL 749
• ANSI/AHAM DW-1-
1992
A. ON-OFF Button
Press this button to
switch the appliance on.
B. ON-OFF Indicator light
This light informs you that
the dishwasher is on.
C. Delayed start select
button
This button delays the start
of the wash cycle you
selected by 2, 4 or 6 hours.
D. Delayed start indicator
light
This indicates that the
delayed start has been set
E. Extra drying button
Press this button for
improved drying.
F. Handle for opening
door
models with door only
P. Cycle select button
Each time this button is
pressed, one of the cycle
indicator lights M will
come on in sequence.
Q. Rack selection button
Press it to choose whether
you want the dishes on the
upper rack to be washed.
R. Upper Wash indicator
light
Displays the selection for
the washing on the upper
rack only.
M.Cycle indicator light
This light informs you which
cycle you have selected or
the one in progress.
S. Low salt indicator light
To tell you that it’s time to
add more salt.
T. Low rinse aid indicator
light
To tell you that it’s time to
add more rinse aid.
Technical characteristics
Width inches 23.42- 24*(59 cm.)
Depth inches 22,44- 23.22 with door) (57-59 cm.)
Height inches 32 1/4 -34 1/2 (82-87,5 cm.)
Capacity 12 standard place settings
Mains water pressure 4,3 psi-145 psi, 30 KPa÷1MPa (0,3 ÷10 bar)
Power voltage See data plate
Total absorber power See data plate
Fuse See data plate
* with the pre-installed filler strips
A B M P E S T Q R
C D
F
Get to know the parts which make up your
dishwasher.
E
H
L
K
F
M
J
I
G
Let's open up your dishwasher together
