DETAILED ENGINEERING DESCRIPTION - CONTINENTAL INDUSTRIE

DEB031EN – 04/2010

1/4



DETAILED ENGINEERING DESCRIPTION AND MECHANICAL

FEATURES OF CONTINENTAL INDUSTRIE MULTISTAGE CENTRIFUGAL

BLOWER MODEL 031A

I - BLOWER HOUSING

The centrifugal blower housing consists of an inlet head with special feature to direct air to
inlet of first impeller and outlet head of special design to eliminate friction and multiple
intermediate sections. These parts are made in cast iron EN-GJL-250 (ASTM A48-35B) (for
I/O heads) & cast aluminium (for intermediate sections) according to rigid Continental
Industrie specifications, extreme care to be exercised in assembly of interlocking cast
aluminium intermediate sections and annular diffusers (baffles).

The entire assembly is securely held together actually with multiple tension rods which bind
the entire housing into a solid integral unit.

1.0 Inlet

head

1.1 Flange connection DN 150, PN 10 (6”)

1.2 Cast iron EN-GJL-250 (ASTM A48-35B)

1.3 Minimum wall thickness: 8 mm (0.31”)

1.4 Can be supplied in various flange positions relative to the vertical centre line in

increments of 90° (option)

2.0 Outlet

head

2.1 Flange connection DN 150, PN 10 (6”).

2.2 Cast iron EN-GJL-250 (ASTM A48-35B).

2.3 Minimum wall thickness: 8 mm (0.31”)

2.4 Can be supplied in various flange positions relative to the vertical centre line in

increments of 90° (option)

3.0 Intermediate

section

3.1 Cast aluminium EN-AC-42000 (ASTM 360.1).

3.2 Each intermediate section is cast in one piece

4.0 Bearing

housing

The outboard bearing housings are cast iron and bolted to the outside of the head sections
insuring cool operation of bearings.

4.1 Cast iron EN-GJL-250 (ASTM A48-35B).

4.2 Has cast fins to improve rigidity and increase heat dissipation

4.3 Labyrinth type grease seal

4.4 Provided with 2 tapped holes in the housing flange to act as bearing puller.

N.B.: When the inlet air or gas temperature is too high, we can adapt as option special
bearing housings with a water or air cooling system (technical drawing on request).
