Page 6
4
6 Technical Specifications
Table 3 includes the technical specifications:
Table 3: Technical Specifications of the CVG-VP6xl 1:6 VGA Distributor
Input:
Analog red, green, blue signals - 0.7 Vpp / 75 , H & V sync, TTL
level, on an HD15F connector
Outputs:
6 analog red, green, blue signals - 0.7 Vpp / 75 , H & V syncs,
TTL level, on HD15F connectors
Video Bandwidth: 400 MHz -3dB
Diff. Gain:
0.03%
Diff. Phase:
0.05 Deg.
Coupling:
DC
K-Factor:
<0.05%
S/N Ratio:
75.8 dB
Power Source:
230 VAC, 50 / 60 Hz (115VAC, U.S.A.) 7.4 VA
Dimensions:
19 inch (W), 7 inch (D) 1U (H) rack mountable
Weight:
2.4 kg. (5.3 lbs.) approx.
Accessories:
Power cord
