Comprehensive CVG-VP3xl User Manual
Page 5
3
4.1 Your CVG-VP3xl 1:3 VGA/UXGA Distributor Underside
Figure 2 and Table 3 define the underside ID BIT Control switches:
Figure 2: CVG-VP3xl 1:3 VGA/UXGA Distributor Underside
Table 3: CVG-VP3xl 1:3 VGA/UXGA Distributor Underside Features
# Feature
Function
1 PIN 11 ID BIT CONTROL Switch Slide to the left to set to ON
1
; to the right to set to OFF
2 PIN 4 ID BIT CONTROL Switch Slide to the left to set to ON
1
; to the right to set to OFF
1 The default. Enabling the notebook or laptop to output a VGA signal to an external VGA monitor
