RGBHV/Stereo Audio Matrix Switcher
14
16、Clear the preset command [Y]: Clear[Y].
Example: To clear the preset command No.5. Run Command: “Clear5.”
9. Technical Specifications
Video Input
Video Output
Input
8 RGBHV
Output
8RGBHV
Input Connector
Female BNC
Output Connector Female BNC
Return Loss
<-30dB@5MHz
Return Loss
-30dB@5MHz
Input Level
0.5 ~ 2.0Vp-p
Output Level
0.5 ~ 2.0Vp-p
Input Impedence 75Ω
Output Impedence 75Ω
DC Offset
1.5V
Switching Type
Vertical interval
Video General
Gain
0 dB
Bandwidth
450MHz (-3dB), fully load
Video Signal
RGBHV, RGBS, RGsB,
RsGsBs, component video,
S-video, and composite video.
Video Type
RGBHV, RGBS, RGsB,
RsGsBs, component video,
S-video, and composite video .
Switching Speed
200ns (Max.)
Crosstalk
<-80dB@5MHz
Audio Input
Audio Output
Input
8 stereo, balanced/unbalanced Output
8 stereo, balanced/unbalanced
Input Connector
Captive screw connectors, 5
pole
Output Connector
Captive screw connectors, 5
pole
Input Impedance
>10KΩ
Output Impedance 50Ω
Audio General
Frequency
Response
20Hz ~ 20KHz
CMRR
>90dB@20Hz~20KHz
Stereo Channel
Separation
>80dB@1KHz
THD + Noise
0.03%@1KHz at nominal
level
Control Parts
Serial Control Port
RS-232, 9-pin female D
connector
Pin Configurations 2 = TX, 3 = RX, 5 = GND
IR Remote
Default IR remote
Front Panel
Control
Buttons
Options
TCP/IP control by PTNET(PTN's programmable interface)
General
Power Supply
100VAC ~ 240VAC, 50/60Hz
Power
Consumption
30W
Temperature
-20 ~ +70
℃
Humidity
10% ~ 90%
Case Dimension
W483 x H87 x D260mm
(2U high, full rack wide)
Product Weight
4.5Kg
