9.0 REGULATORY COMPLIANCE
The Comprehensive CSW series HDMI Switchers have been tested for
compliance with appropriate FCC and CE rules and regulations and are also
RoHS compliant.
The Power Adaptor/Supplies have been tested for compliance with UL, CE, CEC
and CSA rules and regulations and are also RoHS compliant.
10.0 APPENDIX A: RS-232 CODE INFORMATION
Transmission Format:
Baud Rate: 57600 BPS
Data Byte:
8 bits
Parity: None
Stop Bit: 1
Modem Cable Pinouts:
Switcher End Controller End
Pin Definition Pin Definition
1 NC 1 NC
3 TxD 2 RxD
2 RxD 3 TxD
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
2X1 Commands:
Command Code Description
0x01 Port 1 On
0x02 Port 2 On
0x05 Power On/Off
