Comprehensive CSW-HD201C - Manual (Page 4)

The HDMI Switcher 2× 1 Pigtail
３
Se
lec
t
In
p
u
t 1
In
p
u
t 2
1
2
5.0 CONNECTION AND OPERATION
1) Connect the HDMI input sources to the HDMI Switcher. (Input cables are
optional)
*Please refer to connection diagram section.
2) Connect the fixed HDMI cable (pigtail) to display.
3) Press the “select” button to select input sources.
Attention: Insert / Extract cable gently.
5.1 CONNECTION DIAGRAM
