HDMI Twisted Pair
- 3 -
Index:
1. General Instruction .................................................................................................................................. 3
2. Product Picture ......................................................................................................................................... 3
3. Features .................................................................................................................................................... 3
4. Specification ............................................................................................................................................ 4
5. Function Description ............................................................................................................................... 5
6. Installation Introduction ........................................................................................................................... 7
7. Diagram and Connection ......................................................................................................................... 7
8. Twisted Pair Cable Connection ................................................................................................................ 8
9. Panel Drawing ......................................................................................................................................... 8
1. General Instruction:
CE-HDBT100 is an HDMI/IR/RS232 twisted pair including transmitter (CE-HDBT100T) and receiver (CE-HDBT100R).
The CE-HDBT100 uses HDBaseT technology to deliver HDMI signal and control signal (IR & RS232), over a single STP
cable, max transmission distance up to 70 meters with CAT5e/CAT6 cable.
2. Product Picture:
3. Features:
· Support Full HD: Delivers high resolution image (1080p@60Hz@48 b/pixels/3D/4Kx2K).
·
Max transmission distance is up to 70 meters over single CAT5e/CAT6 cable.
TPHD402R Receiver
