VGA SPLITTER 1×8 with audio
３
Operating Temperature 0℃ to +70℃
Operating Humidity 10% to 85 % RH (no condensation)
Storage Temperature -10℃ to +80℃
Storage Humidity 5% to 90 % RH (no condensation)
Power Requirement
External Power Supply 5V DC@2A
Power consumption (Max) 5W(max)
Regulatory Approvals
Converter Unit FCC,CE,UL
Power Supply UL,CE,FCC
Accessories Adapter
AC Power Adapter US standard, UK standard and so on
User Manual
Note: Specifications are subject to change without notice.
3.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the shipping carton:
1) Main unit
2) 6 feet VGA cable(M-F)
3) 5V/2A DC Power Supply.
4) User
’s Manual.
4.0 PANEL DESCRIPTIONS
5.0 CONNECTION AND OPERATION
1) Connect the supplied VGA cable(M-F) from VGA device into VGA input of the
main unit.
2) Connect stereo audio cable(M-M) from audio device into the audio input of the
main unit.
