AVALON RF, INC. Page 6
MX416 User’s Guide & Operating Manual
The receiver interface is:
Pin
Number
Function
1 Power/Signal Return (-)
2 Speaker/ Audio output
3 N/C (No Connection)
4 Power Input (+)
Figure C – I/O Interface
