Specifications b, Figure 1 - specifications – CM-ET Hurricane 360 User Manual
Page 5
5
Product
Code
Load
Rating
(Tonne)
Lift
(ft.)
Net
Weight
(lbs.)
Hand
Chain Pull
to Lift
Rated
Load
(lbs.)
Hand Chain
Overhauled
to Lift Load
One Foot
(ft.)
Dimensions (in)
A
B
C
D
E
F
G
H
J
K
L
M
N
5623A
5624A
5625A
1/2
10
15
20
20
21
23
44
30
11 13/16
11/16
15/16
9/16
5 1/2
8 1/8
3 3/8
2 3/8
5 13/16
5 1/4
5 13/16
15/16
4 5/16
5626A
5627A
5628A
1
10
15
20
29
31
34
54
49
13 3/16
7/8
1 1/8
3/4
6 7/16
9 1/2
3 7/8
2 3/4
6 5/8
6 1/8
6 7/8
15/16
4 15/16
5629A
5630A
5631A
2
10
15
20
44
49
53
74
71
15 9/16
1 3/16
1 3/8
7/8
7 9/16
11 1/8
4 3/8
3 1/4
7 5/8
7 3/16
8
1 1/4
6 1/8
5635A
5636A
5637A
3
10
15
20
64
71
78
92
87
20 1/2
1 1/2
1 9/16
1 3/16
8 7/8
13 3/16
4 7/8
3 3/4
8 5/8
8 11/16 9 13/16
1 5/16
7
5639A
5640A
5641A
5
10
15
20
84
98
113
76
174
25 3/4
1 3/4
1 7/8
1 7/16
9 1/2
13 7/8
4 7/8
3 3/4
8 5/8
8 11/16 9 13/16
13/16
11 1/4
5643A
5644A
5645A
10
10
15
20
157
178
200
102
261
32 1/2
2 11/16 2 11/16 1 15/16 12 13/16 17 3/16
4 7/8
3 3/4
8 5/8
8 11/16 15 1/16
5 3/8
15 13/16
1
Figure 1 - Specifications
SPECIFICATIONS
B
