Y1-03-0232D 3
SECTION1 - PRODUCT DESCRIPTION
Introduction
The RCL-300A was specially designed for mariners who require a high
intensity remote controlled searchlight that can stand up to the tough
marine environment.
The sleek design and modern construction of the searchlight body
makes it attractive for recreational and commercial vessels. The
searchlight is totally enclosed and is made of rugged aluminum alloy. It
is gasketed and finished to be resistant to the weather.
The RCL-300A searchlight contains a narrow beam searchlight that
produces 1,000,000 peak candle power by combining twin 35W metal
halide HD lamps providing over 500K candela (CD) each and 1 million
effective CD when combined.
All functions of the searchlight can be electrically operated by remote
control from the pilot area od the vessel using the URP-102 Point
Pad™, URC Master Controller and interconnect cable supplied with the
RCL-300A. Searchlights equipped with the URC-300 Master Controller
have a self-
park feature and ACR’s unique XRCiZ™ feature. The
XRCiZ™ feature routinely operates all moving parts in the searchlight to
keep the motors and drive mechanisms freely running.
Unpacking the RCL-300A
Your new RCL-300A Remote Control Searchlight System comes with
the following components:
1.) RCL-300A searchlight
2.) URP-
102 Point Pad™ with Installation Kit
3.) URC-300 Master Controller with Installation Kit
4.) Product Support Manual, Warranty Card, Mounting Templates, etc.
5.) Coaxial Cable Kit
