SWITCHERS

11

ACCESSORIES

8

Model No.

Description
TABLE MOUNT HARDWARE

TM1276

Table Mount bracket for 2U ½ Rack-
Wide
RACK MOUNTING ACCESSORIES

DA1298RM

Rack mount shelf for two units side by
side

DA1299RM

Rack mount kit for single unit.
CONTROL CABLES

RC5204CC

Analog to contact Closure Adapter 6 ft

RC5207CC

RS-232/Master-Slave Control cable
HIGH RESOLUTION 4 BNC to 4 BNC
COAXIAL CABLE

CB4100MR

Bulk Cable 4 coaxes (500ft minimum)

CB4103MR

3 feet, 4 BNC to 4 BNC coaxial cable

CB4106MR

6 feet, 4 BNC to 4 BNC coaxial cable

CB4112MR

12 feet, 4 BNC to 4 BNC coaxial cable

CB4125MR

25 feet, 4 BNC to 4 BNC coaxial cable

CB4150MR

50 feet, 4 BNC to 4 BNC coaxial cable

CB4175MR

75 feet, 4 BNC to 4 BNC coaxial cable

CB41100MR 100 feet, 4 BNC to 4 BNC coaxial cable
CB41150MR 150 feet, 4 BNC to 4 BNC coaxial cable

SUPER HIGH RESOLUTION 4 BNC to
4 BNC COAX

CB4300MR

Bulk Cable 4 coaxes (500ft minimum)

CB4306MR

6 feet, 4 BNC to 4 BNC coaxial cable

CB4312MR

12 feet, 4 BNC to 4 BNC coaxial cable

CB4325MR

25 feet, 4 BNC to 4 BNC coaxial cable

CB4350MR

50 feet, 4 BNC to 4 BNC coaxial cable

CB4375MR

75 feet, 4 BNC to 4 BNC coaxial cable

CB43100MR 100 feet, 4 BNC to 4 BNC coaxial cable
CB43150MR 150 feet, 4 BNC to 4 BNC coaxial cable

POWER CABLES

PC5301US

Power cable for US

PC5302US

Power cable for U.K.

PC5303US

Power cable for Australia

PC5304US

Power cable for Germany

FREQUENTLY ASKED QUESTIONS

9

No:

Question

Answer

1

When I
press F1
nothing
happens.
What is a
purpose of
this
function?

The F1 function is reserved for
future use. It does not perform
any functions at the present
time.

2

What is the
LED next to
the F1
button used
for?

This LED is also reserved for
future use. It is currently non-
operational.

3

When I
press the
RESET
button, the
switcher
does not
respond.
Why?

You must press and hold the
button for approximately 2
seconds, until you hear a
beeping sound and all of the
LED lights flash. This is
designed to avoid accidental
resetting.

4

Can the
MX2216RM
be rack
mounted?

The MX2216RM can be rack
mounted as a single unit or
two units side by side. The
width of the unit is 1/2 rack
wide. Altinex offers rack mount
ears for single unit mounting
(part# DA1299RM) and rack
shelf for mounting two units
(part# DA1298RM).

5

Can the
MX2216RM
be used to
pass
Composite
Video, S-
Video or
Component
Video?

Yes. Simply use the
corresponding channels to
pass the signals (e.g. For
composite video, you may use
the Red input channel and the
Red output channel, or you
can use the Blue input channel
and Blue output channel).
Since the MX2216RM is a
relay switcher, it can be used
as a contact closure control or
to switch virtually any type of
video signal.

6

Can the
MX2216RM

Yes, the MX2216RM uses a
universal internal power
