7 IOM-3500
MODEL 3500 PRESSURE RELIEF VENT WITH PIPE-AWAY
ITEM NO. METAL BODY PART LIST FRP BODY PART LIST
2 Cover Assembly Cover Assembly
3 Seat Ring Integral Part of Item 1
4 Pallet Pallet
5 Diaphragm Diaphragm
6 Diaphragm Retainer Plate - Pressure Diaphragm Retainer Plate - Pressure
10 Pressure Pallet Stem Integral Part of Item 4
11 Seat Ring Bolts Not Required
12 Cover Gasket (Gortex Rope) Cover Gasket (Gortex Rope)
13 Seat Ring Gasket Not Required
16 Pressure Pallet Guide Integral Part of Item 1
18 Weight Weight
19 Lock Washer Not Required
20 Pipe-Away Body Pipe-Away Body
21 Drain Plug Not Required
22 Cover Bolts Cover Bolts
23 Pallet Nut/Bolt Pallet Nut/Bolt
24 Plain Washer Not Required
25 Spool Piece Integral Part of Item 1
31 Pipe Plug Not Required
42 Stiffener Plate Not Required
61 Cotter Pin Not Required
69 Stud Spacer Not Required
