The board has two modes of operation: DEMO and USER. Use DEMO
mode to run the sample program included with the kit. Run the board in
USER mode:
•
When using the ZDI port to debug your code.
•
When configuring the board to run your own prototype code.
DEMO Mode Jumper Settings
When running the board in DEMO mode, the following jumpers MUST
be set:
J7
OUT
DEMO mode setting
X
IN
Chip U5 resets when SW1 pressed
J8
1-2
Connects U5 pin PA3 to J11 pin 1
(CTS0 EN)
X
2-3
Connects U5 pin PA3 to JP2 pin 35
J9
1-2
Connects U5 pin PA4 to RXD
RS232 signal
X
2-3
Connects U5 pin PA4 to JP2 pin 35
J10
1-2
Connects U5 pin PA5 to TXD
RS232 signal
X
2-3
Connects U5 pin PA5 to JP2 pin 36
J11
OUT
Disconnects PA3 from CTS0
RS232 signal
X
IN
Connects PA3 to CTS0 RS232
signal
Note: * These jumpers must not be OUT at the same time
Table 1. Z8F04A08100KIT Jumper Functions
Jumper
State
Description
Default
