094096, Exploded Parts List

Automatic Electric Drain Assembly, AED-1

Item

# Part

# Description

Qty

1

030016

Elbow, 90 Degree, ¾ “FPT X ¾”MPT

1

2

080077

Valve, Drain, ¾”FPT, Normally Open

1


3 080121 Clamp,

Gear,

1-1/4” 1

4 052005 Tubing,

1”

X

1-1/4” 1


5

030015

Coupler, ¾”MPT X 1”HB

1

6

030009

Valve, Ball, ¾”FPT, Both Ends

1


7 030017 Nipple,

Close,

¾”MPT

1

8

030018

Elbow, 90 Degree, ¾”FPT

1


9

030021

Nipple, ¾”MPT X 3”

1

10

500310

PWS AED Motor Assembly, W/Cord, 120V 1

500311

PWS AED Motor Assembly, W/Cord, 240V 1

01/19/04 PAGE 16 097063S13
