1
Performance Data Sheet and Specification
Item
Number
Model
Number
Capacity - Grains
Service
Flow Rate
USGPM (LPM)
Maximum
Flow to Drain
USGPM (LPM)
Resin
Tank Size
inches (mm)
Brine
Tank Size
inches (mm)
Resin
Volume
cu.ft. (litres)
Salt
Capacity
lbs (kg)
Shipping
Weight
lbs (kg)
@ 15lbs/
cu.ft.
Factory set
@ 10 lbs/cu.ft.
@ 6lbs/
cu.ft.
Twin Tank Models
7600 5600MI-20 22,000 20,000 15,000 8 (30.3) 1.2 (4.5)
8 x 47
(203 x 1194)
18 x 35
(457 x 889)
0.75 (21.2) 224 (101.6) 90 (40.8)
7710 5600MI-20 (8x44) 22,000 20,000 15,000 8 (30.3) 1.2 (4.5)
8 x 44
(203 x 1117)
18 x 35
(457 x 889)
0.75 (21.2) 224 (101.6) 90 (40.8)
7601 5600MI-30 30,000 27,000 20,000 10 (37.9) 1.5 (5.7)
9 x 48
(229 x 1219)
18 x 35
(457 x 889)
1.0 (28.3) 224 (101.6) 105 (47.6)
7711 5600MI-30 (10x35) 30,000 27,000 20,000 10 (37.9) 1.5 (5.7)
10 x 35
(254 x 889)
18 x 35
(457 x 889)
1.0 (28.3) 224 (101.6) 105 (47.6)
7602 5600MI-45 45,000 41,000 30,000 11 (41.6) 2.0 (7.6)
10 x 54
(254 x 1372)
21 x 36
(533 x 914)
1.5 (42.5) 308 (139.7) 140 (63.5)
7603 5600MI-60 60,000 55,000 40,000 15 (56.8) 3.0 (11.4)
12 x 52
(305 x 1321)
21 x 36
(533 x 914)
2.0 (56.6) 308 (139.7) 185 (83.9)
7604† 5600MI-90 90,000 82,000 60,000 15 (56.8) 4.0 (15.1)
14 x 65
(356 x 1651)
21 x 36
(533 x 914)
3.0 (84.5) 308 (139.7) 255 (115.7)
Cabinet Models
7378† WTC5620 20,000 18,000 13,000 6 (22.7) 3.0 (11.4)
8 x 35
(203 x 889)
21 x 13 x 44
(533 x 330 x 1118) 0.67 (18.9)
359 (162.8) 73 (33.1)
7379 WTC5630 30,000 27,000 20,000 10 (37.9) 4.0 (15.1)
10 x 35
(254 x 889)
21 x 13 x 44
(533 x 330 x 1118) 1.0 (28.3)
359 (162.8) 90 (40.8)
WQA Tested and
Certified against
CSA B483.1
How Your 5600 MI-DF Water Conditioner Works
Hard water enters your home through the main supply line, enters your water conditioner, and passes down through a bed of ion
exchange resin which softens and filters the water as well. An ion exchange process takes place in which the resin beads capture and
hold calcium and magnesium, the hardness impurities, while the water takes on sodium ions. The soft water then flows up and into your
household water line.
Your meter initiated water conditioner is set by aligning the number of people with the grains of hardness on the program wheel. See
Operating Instructions.
On the days your conditioner regenerates, the resin is automatically recharged by passing a brine solution (salt water) through it. This
reverses the ion exchange process, charging the resin with sodium and freeing the hardness minerals. These minerals and the brine
solution are then flushed away through the drain line followed by a rapid rinse. The resin bed is again ready to soften water. The proper
volume of water is returned to the brine tank to dissolve enough salt for the next regeneration. All this is performed automatically.
† Not certified by WQA
Working Temperature: 34-110°F (1-43°C)
(Do not subject unit to freezing temperatures).
Working Pressure: 20-125 psig (137-861 kPa)
Electrical: Standard 120V / 60 Hz
Pipe size: 3/4”
• Capacities of softeners may deviate from the chart above depending on flow rates and
raw water conditions.
• The manufacturer reserves the right to make product improvements which may deviate
from the specifications and descriptions stated herein without obligation to change
previously manufactured products or to note the change.
• Do not use water that is microbiologically unsafe without adequate disinfection before or
after the system.
