Model HT13GXR Overall Dimensions

SPECIFICATIONS

167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website

:

www.hydra-tech.com

E-Mail

:

[email protected]

ENGINE:............................................................. Honda GX390 Gasoline
HORSEPOWER:.............................................................13 @ 3500 RPM
HYDRAULIC OUTPUT:............................ Variable Max 6 GPM (23 LPM)
OPERATING PRESSURE:........................ Maximum 2100 PSI (143 Bar)
HOSE PORT SIZE:......................................................... 1/2" or 3/4" NPT
HYDRAULIC OIL:.......................................... SAE 10W or 20W Type AW

also: Dexron ATF or Biodegradable Oil

OIL FILTRATION:.................................................... 10 Micron (Standard)
OIL RESERVOIR CAPACITY:.......................... 8 U.S. Gallons (30 Liters)
FUEL TANK CAPACITY:................................. 15 U.S. Gallons (57 Liters)
FUEL CONSUMPTION:................. Approx. .9 U.S. Gal/Hr (3.4 Liters/Hr)
DIMENSIONS:... H 37 1/2" (95 cm) x W 33 1/2" (85 cm) x L 50" (127 cm)
WEIGHT (Dry):............................................................... 355 lbs. (161 kg)

* For Flows and Pressures Other Than Standard, Consult Factory

Since we are constantly working to improve our products, specifications are subject to change without notice.

37 1/2" (95 cm)

50"

(127 cm)

33 1/2"

(85 cm)
