Model HT15DH Overall Dimensions
SPECIFICATIONS
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
:
ENGINE:............................. Hatz 1D81Z D Air-Cooled Diesel (Int. Tier 4)
HORSEPOWER:............................................................ 15 @ 3000 RPM
HYDRAULIC OUTPUT: (Std.)................ Variable, Max. 9 GPM (34 LPM)
OPERATING PRESSURE: (Std.).............. Maximum 2000 PSI (136 Bar)
HOSE PORT SIZE:..................................................................... 3/4" NPT
HYDRAULIC OIL:.......................................... SAE 10W or 20W Type AW
also: Dexron ATF or Biodegradable Oil (Consult Factory)
OIL FILTRATION:.................................................... 10 Micron (Standard)
OIL RESERVOIR CAPACITY:....................... 30 U.S. Gallons (114 Liters)
FUEL TANK CAPACITY:.................................. 1.8 U.S. Gallons (7 Liters)
FUEL CONSUMPTION:....................... Approx. .75 Gal/Hr (2.8 Liters/Hr)
DIMENSIONS:............... H 34" (86 cm) x W 32" (81 cm) x L 48" (122 cm)
WEIGHT (Dry):............................................................... 600 lbs. (272 kg)
* For Flows and Pressures Other Than Standard, Consult Factory
Since we are constantly working to improve our products, specifications are subject to change without notice.
48"
34"
(86
cm)
(122 cm)
32"
(81 cm)
