Hydra-Tech HT7DXR User Manual
Page 2
Model HT7DXR Overall Dimensions
SPECIFICATIONS
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
:
ENGINE:.................................................................. Yanmar L70V Diesel
HORSE POWER:............................................................. 7 @ 3500 RPM
HYDRAULIC OUTPUT:........................ Variable, Max 4.5 GPM (17 LPM)
OPERATING PRESSURE:........................ Maximum 1800 PSI (122 Bar)
HOSE PORT SIZE:..................................................................... 1/2" NPT
HYDRAULIC OIL:.......................................... SAE 10W or 20W Type AW
also:. Dexron ATF or Biodegradable oil
OIL FILTRATION:.................................................... 10 Micron (Standard)
OIL RESERVOIR CAPACITY:.......................... 8 U.S. Gallons (30 Liters)
FUEL TANK CAPACITY:................................. 15 U.S. Gallons (57 Liters)
FUEL CONSUMPTION:................ Approx. .3 U.S. Gal/Hr (1.1 Liters/Hr)
DIMENSIONS:.. H 37 1/2" (95 cm) x W 33 1/2" (85 cm) x L 50" (127 cm)
WEIGHT (Dry):............................................................... 380 lbs. (172 kg)
* For Flows and Pressures Other Than Standard, Consult Factory
Since we are constantly working to improve our products, specifications are subject to change without notice.
37 1/2" (95 cm)
50"
(127 cm)
33 1/2"
(85 cm)
