Hydra-Tech HT35DYS User Manual
Page 2
Model HT35DYS Overall Dimensions
SPECIFICATIONS
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
:
ENGINE:..................... Yanmar 3TNV88 Liquid Cooled Diesel (Tier 4 Int.)
POWER:...................................................... 35 HP(26 KW) @ 3000 RPM
HYDRAULIC OUTPUT*:...................... Variable, Max. 20 GPM (76 LPM)
OPERATING PRESSURE*:....................... Maximum 2500 PSI (170 Bar)
HOSE PORT SIZE:..................................................................... 3/4" NPT
HYDRAULIC OIL:.................. SAE 10W or 20W (ISO 32 or 46) Type AW
................................................. also: Biodegradable oil (Consult Factory)
OIL FILTRATION:.................................................... 10 Micron (Standard)
OIL RESERVOIR CAPACITY:....................... 30 U.S. Gallons (113 Liters)
FUEL TANK CAPACITY:............................... 42 U.S. Gallons (159 Liters)
FUEL CONSUMPTION:............... Approx. 1.5 U.S. Gal/Hr (5.7 Liters/Hr)
DIMENSIONS:......... H 64" (163 cm) x W 58" (147 cm) x L 105" (267 cm)
WEIGHT (Dry):............................................................. 1420 lbs. (643 kg)
* For Flows and Pressures Other Than Standard, Consult Factory
Since we are constantly working to improve our products, specifications are subject to change without notice.
64"
58"
(163 cm)
(147 cm)
105"
(267 cm)
