Model HT50DQV Overall Dimensions
SPECIFICATIONS
167 Stock Street, Nesquehoning, PA 18240 Phone: 570-645-3779 Fax: 570-645-4061
Website
:
ENGINE:......................................... Yanmar 4TNV84T Diesel (Tier 4 Int.)
HORSEPOWER:............................................................ 50 @ 2800 RPM
HYDRAULIC OUTPUT*:...................... Variable, Max. 25 GPM (95 LPM)
OPERATING PRESSURE*:....................... Maximum 3000 PSI (204 Bar)
HOSE PORT SIZE:................................ (Pressure and Return).. 1" NPT
(Case Drain).. 1/2" NPT
HYDRAULIC OIL:...................... (Standard) SAE 20W (ISO 46) Type AW
also: Biodegradable oil (Consult Factory)
OIL FILTRATION:.................................................... 10 Micron (Standard)
OIL RESERVOIR CAPACITY:...................... 38 U.S. Gallons (144 Liters)
FUEL TANK CAPACITY:............................... 75 U.S. Gallons (284 Liters)
FUEL CONSUMPTION:............... Approx. 2.5 U.S. Gal/Hr (9.5 Liters/Hr)
NOISE LEVELS @ 2800 RPM:. 79dB @ 3 Ft. (1M), 64dB @ 23 Ft. (7M)
DIMENSIONS:............. H 56" (142 cm) x W 36" (91 cm) x L 78" (198 cm)
WEIGHT (Dry):........................................................... 2400 lbs. (1087 kg)
* For Flows and Pressures Other Than Standard, Consult Factory
Since we are constantly working to improve our products, specifications are subject to change without notice.
84" (213 cm)
Q-PAK
HT50DQV
36" (91 cm)
58" (147 cm)
