Model DL-010
Not gate
12
2-Input AND gate
12
4-Input AND gate
8
2-Input OR gate
8
4-Input OR gate
8
2-Input XOR gate
12
LEDs
8
7-Segment LED display
1
Slide switch
8
Push Button switch
1
270 tie point Bread Board
yes
Vcc & GND tie points
yes
Hook up wire, 100pcs
yes
9V wall adaptor
yes
Regulated 5V supply
yes
DL-010 Manual
yes
Width
13.5 in
Length
8.5 in
Height
3.5 in
Weight
3.40 lbs
Technical data subject to change without notice
Analog &
Digital
Design
Workstation
Innovative Training Solutions globalspecialties.com
©2012 Global Specialties 22820 Savi Ranch Parkway Yorba Linda, CA 92887 1-800-572-1028
Embedded Systems Design Series
Digital Logic Trainers
Specifications
Training Manual
Chapter 1:
Combinational Logic Design
Trainer
Model DL-010
Chapter 2:
Microprocessors
Introduction to Microprocessors
Combinational and Sequential Circuit
Analogy
Chapter 3:
Digital Logic Circuits
Basic Logic Gates
Digital Circuits
Identifying Combinational Circuits
Analysis of Combinational Circuits
Boolean Algebra
Simplifying Combinational Circuits
Synthesis of Combinational Circuits
Chapter 4:
Labs
Basic Gates, Lights and Action!
NAND, NOR, XOR, AND XNOR Gates
Designing Combinational Circuits
Multiplexers
Decoders
Comparators
Full Adder
4-bit Adder
4-bit Adder/Subtractor
2-bit Arithmetic and Logic Unit (ALU)
BCD to 7-Segment LED Decoder
Combinational
Logic Trainer
DL-010
