PB-500

Specifications

Innovative Training Solutions

www.globalspecialties.com

© 2011 Global Specialties

22820 Savi Ranch Parkway

Yorba Linda, CA 92887

1.800.572.1028

Optional Accessories

Courseware: Available separately or as a

package (Model PB-500 Lab).

WK-1: Jumper Wire Kit, 350 pieces
WK-2:
Jumper Wire Kit, 140 pieces
WK-3: Jumper Wire Kit, 70 pieces
WK-4: Wire Jumper Kit, 100 wires with

machined tips

GSPA Series: Prototyping adapters
GSPA-K1: Surface mount to DIP adapter

kit, 6 adapter boards

GSPA-K2: Surface mount to DIP adapter

kit, 11 adapter boards

GSA-3185: Minipro Test Clip Set

The PB-500 Lab package offers

comprehensive course instruction
covering the following areas:

Fundamentals of Electricity

Ohm’s Law

Series Circuits, Parallel Circuits

Combinational Circuits

Current Control

Closed, open, shorts

Switches

Thevenin’s Theorem

Wheatstone Bridge

Capacitors, Inductors

Phase Shift Circuits

Impedance

Resonant Circuits

Transformers

Rectifiers & Filtering

Integrated Circuits

Transistor Amplifiers

Oscillators

Analog
Circuit
Trainer


Model



PB-500

Input power

Source

Regulated wall mount adapter with outputs of
+/-12VDC @ 200mA, 5VDC @ 250mA

Power Supplies

Fixed - 12VDC @ 200mA +/- 5%
Fixed - (-)12VDC @ 200mA +/- 5%
Variable - 0 to 7.5VDC @ 50mA +/- 10%
Variable 0 to (-) 7.5VDC @ 50mA +/- 10%

Function

Generator

Frequency: Factory set to 1Khz. Variable with
use of external capacitor from 0.1Hz to 100Khz
Sine Wave: 4V pk to pk in 10k ohm load
Triangle Wave: 9V pk to pk in 10k ohm load
Square Wave: 8V pk to peak in 10k ohm load
TTL: Logic "0" @ 0.3V max, Logic "1" @ 1.4V
min in TTL load. Rise and fall times less than
1µsec
Duty Cycle: 50% for all Waveforms

Slide

Potentiometers

(2) 1K & 10K

Slide Switches

(3) Single Pull Double Throw Type

Connectors 2 ea BNC

Speaker

8 Ω, 0.25 W

Breadboards

840 tie points with (8) 25 pin power rails and
accommodates up to 8 (14 pin) ICs

Weight 1 lb, 10oz (Minus Adapter) (0.5 kg)

Dimensions 10 x 7.5 x 2.6" (254 x 190 x 66 mm)

Technical data subject to change without notice.
