6
SPECIFICATIONS
Input Power Source 108 to 130VAC @ 60Hz
Power Supplies
Fixed: +5V +/-0.2VDC, 1.0A max, current limited
Load Regulation better than 0.8% +/- 0.02%/°C
Ripple, <4mVp-p @1A
Variable: Factory Set to +15VDC, with internal
adjustment +5.5 to 18VDC, 0.5A max@ +15VDC
Load Regulation better than 1% +/- 0.04%/°C,
Ripple less that 10mVp-p @ 0.5A
Variable: Factory Set to -15VDC, with internal
adjustment -5.5 to -18VDC, 0.5A max@ +15VDC
Load Regulation better than 1% +/- 0.04%/°C
Ripple less that 10mVp-p @ 0.5A
Binding Posts
(1) Black: Chassis Ground
(3) Red: Power Supply Outputs +5VDC, +15VDC
& -15VDC
Breadboards
2250 Tie points with (8) 100 pin and (2) 80 pin
power rails and accommodates up to 24 (14 pin)
IC's
Weight 5lb, 5oz
Dimensions 9.8" x 6.6" x 3.3"
