INSTALLATION
1. Cut a 2” round hole in duct or plenum with a hole saw or
duct knife for insertion of the UV lamp.
2. Insert the lamp into the hole. Magnets on the mounting
plate will hold the UV lamp assembly secure – no screws
are necessary. If mounting on ductboard, secure unit
with tape, or cut a piece of sheet metal 4” x 4” and cut 2”
hole in middle. Tape sheet metal plate to ductboard
and insert lamp through holes.
3. Attach power supply in a suitable location and connect the
power supply to 24VAC power.
The MicrobeSwatter ® SweetShot requires a 50 VA
Transformer to correctly power ultraviolet lamp air
purifier.
4. Connect lamp cable from power supply to lamp.
5. If mounting inside duct, order AGMGF magnetic mounting
bracket (accessory not included). Attach UV lamp assembly
to mounting bracket and attach bracket (with magnet on
backside) to any metal surface – no screws are necessary.
The MicrobeSwatter ® SweetShot is designed for air
disinfection, deodorization and surface irradiation and installs
into the air handling system or ductwork. Select a mounting
location that offers sufficient space for the mounting plate
3” x 3” and enough internal space for the UV lamp – 16”. In
addition, allow for sufficient space for removal (pulling out) of
the 16.25” lamp assembly. Installation also requires access to
24 VAC electrical power.
• Do not install where UV lamp is visible
• Do not install in outdoor applications
• Do not expose wiring or plastic to UV light
• Do not install beneath a humidifier
• If installed near an air filter, check with the filter
manufacturer for UV properties & safety.
• The unit can be installed in either the return or
supply air side for for air stream disinfection
or mounted anywhere surface irradiation is needed.
Steps to replace ultraviolet lamps:
1. READ THE WARNINGS ABOVE.
2. Make sure power is off to the HVAC system and the UV
lamp is off before opening any service panels.
3. Remove the rubberized cap covering the center part of the
lamp assembly inserted into the air duct.
4. Pull out the UV lamp assembly (the lamp assembly is held
in place with strong magnets), and insert new UV lamp
assembly.
5. Reattach the rubberized cap making sure the lamp socket is
pushed onto the metal pins tightly.
6. Restore power to the HVAC system.
SPEcIFIcATIONS
REPLAcING ThE LAMP
Dimensions:
• Mounting Plate: 3" x 3"
• UV Lamp 1.75" x 16.25"
• Duct Mounting Hole: 2"
Weight:
• UV Lamp Assembly: 6 oz
Electrical
• 24 VAC, 2 Amp
• UL Listed Electronic Ballast
UV Lamp
• 36 watt, 105 uw/cm² @ 1 mtr
Transformer NOT included
50 VA Required- GA3501 Recommended
AGMGF magnetic mounting bracket
(accessory not included)
WARNING
Electrical Shock –The unit is to be wired into 24 VAC
electrical power.
Component Failure May Result – Dedicated 50 VA
transformer required, not included.
Ultraviolet Light is Harmful – Never look at a lit ultraviolet
lamp without UV protective glasses and skin coverings.
Unplug the lamp before servicing.
Ultraviolet Lamp May Cause Injury – Ultraviolet lamps
are made of glass and therefore somewhat fragile. Safety
glasses and gloves should be worn when handling a UV
lamp. In addition, UV lamps can be very hot and cause skin
burns. Allow lamp to cool before handling.
IMPORTANT
This unit must be installed in compliance and
in accordance with all national, state, and local
electrical and mechanical codes. Failure to do
so will void all expressed or implied warranty
representations.
Installation Manual
General Filters, Inc. 43800 Grand River Ave., Novi, Michigan 48375 • Toll Free (866) 476-5101
Phone: (248) 476-5100 • Fax (248) 349-2366 • www.generalaire.com
Ultraviolet Air Purification System
