Nilfisk-ALTO Nilfisk C 100.4 - Manual (Page 15)

15
Declaration
Manufacturer's name and address or his
authorized representative in the Community Nilfi sk-Advance AG
Nilfi sk Business Unit
Guido-Oberdorfer-Str. 10
89287 Bellenberg
GERMANY
Name of the person responsible for the
technical documentation Wolfgang Nieuwkamp
Description of the equipment:
Equipment name
Model
Dimension
Rated output voltage
Rated frequency
Rated input power High pressure washer
Nilfi sk
C 100.4-5 / C 110.2-5 / C 110.2-5 X-TRA
255 x 240 x 630 mm
AC 230-240 V
50 Hz
1.3 - 1.4 kW
Measured sound pressure level 90 dB(A)
Guaranteed sound power level 92 dB(A)
Declaration The equipment refer in this document fulfi ls all the require-
ments of the Directive :
Machine Directive 98/37/EC
Low-voltage Directive 73/23/EEC
EN 60335-2-79: 2004
EN 60335-1/A1: 2004
EN 50366: 2003
EMC Directive
89/336/EEC
EN 55014-1/A2: 2002
EN 55014-2/A1: 2001
EN 61000-3-2/A2: 2005
EN 61000-3-3/A1: 2001
Outdoor Noise Directive
2000/14/EC
Place and date of the declaration Bellenberg, November 10, 2005
Signature
9 Main Technical Data
Type C 100.4-5 C 110.2-5 C 110.2-5 X-TRA
Rated pressure bar/MPa 65/6.5 70/7.0 70/7.0
Permissible pressure bar/MPa max. 100/10.0 max. 110/11.0 max. 110/11.0
Rated flow l/min 5.3 5.0 5.2
Rated input kW 1.3 1.4 1.4
Rated voltage V 230-240 230-240 230-240
Max. water temperature °C 40 40 40
Inlet pressure bar/MPa 0.15-10/0.015/1.0 0.15-10/0.015/1.0 0.15-10/0.015/1.0
Sound pressure level dB(A) 78 78 78
Guaranteed sound power level dB(A) 92 92 92
Vibration according to ISO 5349 m/s 2 max. 2.5 max. 2.5 max. 2.5
10 Declaration
