Airlink AWLC3025 User Manual
Page 17
-
13 -
Item Description
Mode
Displays the type of connection: Access Point or
Peer-to-Peer.
Ch
Displays the channel that is currently in use.
Signal
Displays the signal strength of the connection
between the Wireless Network Adapter and the
Access Point it connects to.
BBS ID
Displays the MAC address of the target device.
Current
Configuration
Pref. SSID
Shows the current SSID the wireless network
adapter is connected to.
BSS Type
Shows the current connection type: Access
Point or Peer to Peer.
BSSID
The MAC address of the device that the
wireless network adapter is connected to.
Channel
Shows the current channel.
Tx Rate
Shows the current transfer rate.
Signal Quality
Shows the signal strength of the connection
between the wireless network adapter and the
device it connects to.
Connect button
Highlight one of the devices from the device
list and press the Connect button to access it.
Modify button
There will be two tabs for you to modify, see
the detailed information on next page.
Rescan button
Searches all available networks. Clicking on
this button, the wireless adapter will start to
rescan and list all available devices.
