8
PHYSICAL CONNECTIONS
RS-232 Nurse Call Physical Connection
The TTS-1nc allows interfacing to Nurse call systems via RS-232 and supports the TAP protocol. Currently the TTS-1nc supports Rauland
Responder 4 and 5 natively. Two connection modes are supported. Active Mode is supported where the TTS-1nc and Nurse call system
are the only devices used. This provides a fully monitored connection between the Nurse call system and the TTS-1.
Passive mode is supported where existing connections already exist between the Nurse Call system and a third party system. This pro-
vides an unmonitored connection between the Nurse call system and the TTS-1.
Wiring requirements of Active Connection
Wiring requirements of Passive Connection
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9 Not Connected
CD
RxD
TxD
DTR
SG
DSR
RTS
CTS
RI
Nurse Call
System
Third
Party
System
D-9 Female
CD
RxD
TxD
DTR
SG
DSR
RTS
CTS
RI
D-9 Female
1
2
3
4
5
6
7
8
9
CD
RxD
TxD
DTR
SG
DSR
RTS
CTS
RI
D-9 Female
TTS-1
Passive
Mode
The enclosed diagram is indicative. Connection wiring may vary depending on the interfacing hardware. Suitable isolating and
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9 Not Connected
CD
RxD
TxD
DTR
SG
DSR
RTS
CTS
RI
Nurse Call
System
TTS-1
Active
Mode
D-9 Female
CD
RxD
TxD
DTR
SG
DSR
RTS
CTS
RI
D-9 Female
