10
VO-4 SPECIFICATIONS
Vocia Output 4 BLOCK DIAGRAM
Vocia Output 4 SPECIFICATIONS
Frequency Response: 20Hz to 20kHz + or – 1dB Control Outputs
Type:
Max Operating Voltage:
Max Switching Capacity:
Min Operating Load:
Form C Voltage
free change over contact
125VAC, 60VDC
37VA
10µA @ 10mV DC
THD + N (20Hz to 8kHz): <0.02%
Dynamic Range: >80dB Connection: RJ45 with shielded Ethernet/PoE
cable (CAT5, CAT5e, CAT6 or CAT7)
Crosstalk (10kHz): >80dB Power: 802.3af (PoE) Class 3
Minimum Load Impedance: 600k Ω Dimensions:
Height:
Width:
Depth:
0.75 inches (44.5mm)
19 inches (483mm)
10 inches (254mm)
Maximum Output Level: >+22dBu
Nominal Output Level: -10dBu, 0dBu, or +4dBu Weight: 6.4 lbs. (2.9kg)
A/D Converters: 24-bit (48kHz sampling) Ambient Operating
Temperature Range:
32-113 degrees F (0-45 degrees C)
Control Inputs:
Type:
Max Input Threshold:
Max Input Voltage:
Min Input Threshold:
Input Impedance: Digital, variable threshold
10V
12V
150mV
100k Ω
Compliance: FCC Part 15, class B
CE marked
RoHS Directive
UL 60065 Listed, E215636
C-UL Listed, E215636
C-Tick, N24138 (Australia)
Analog
Inputs
ID
Switches
Control
Outputs
Control
Inputs
LEDs
HostProcessor
Gain
CobraNet
audio and
control
D/A PoE
CobraNet
Processor
