1
301 & 601
INTRODUCTION
The 301 & 601 are single rack space, three input & six input mic/line mixers. Each input channel uses a differentially balanced, discrete
transistor mic/line preamplifier for low noise and low distortion performance. Inputs are provided to accept signals from microphones
and/or line level devices. Special features, including limiters and remote level control, make the 301 & 601 extremely versatile. The 301 &
601 mixers are dependable, easy to install, simple to operate, and are covered by Biamp Systems’ five-year warranty.
301 & 601 features include:
♦ three electronic balanced mic/line input channels (301)
♦ six electronic balanced mic/line input channels (601)
♦ 30dB rear panel Pad switch on each input channel
♦ 40dB screwdriver-adjust Trim on each input channel
♦ +10dB Peak LED indicator on each input channel
♦ rotary level control on each input channel
♦ auto-muting of one channel for "talk-over" applications
♦ +24 volt Phantom Power assign switch on each input
♦ electronic balanced main output with rotary level control
♦ remote control of main level from up to 2000 feet away
♦ main patch insert point for external processing devices
♦ main stacking input accepts signals from other mixers
♦ screwdriver-adjust tone controls & limiter on main output
♦ -20dB Signal Present LED indicator for main output
♦ all input/output/control on plug-in barrier strip connectors
♦ covered by Biamp Systems’ five-year warranty
♦ marked and UL / C-UL listed power source
