Serial ATA Flash Drive
AP-SRFD255AXXXXR-G
13
© 2008 Apacer Technology Inc. Rev 0.2 (Preliminary)
Table 3-2: Power segment
Pin Signal / Description
P1 Not Used (3.3V)
P2 Not Used (3.3V)
P3 Not Used
P4 Ground
P5 Ground
P6 Ground
P7 5V Pre-charge
P8 5V
P9 5V
P10 Ground
P11 Ground
P12 Ground
P13 Not Used
P14 Not Used (12V)
P15 Not Used (12V)
