Aqua Flo A Series - Manual (Page 6)

"A" SERIES REPLACEMENT PARTS
Please refer to diagram located on page 7
Ref.
No. Part No. Description
1 Motor, 56 Frame, 'C' Face, Keyed Shaft
2 92520002 20002 Shaft, Extension, Solid End Shaft, Extension, Solid End
3 3 99730000 99730000 Screw, Socket Set, 1/4"-20 x 5/16" Screw, Socket Set, 1/4"-20 x 5/16"
4 4 91140050 91140050 Bracket, .33-2.0 HP Bracket, .33-2.0 HP
4 4 91140100 91140100 Bracket, .33-2.0 HP, With Foot Bracket, .33-2.0 HP, With Foot
4 4 91140150 91140150 Bracket, 3.0 HP Bracket, 3.0 HP
5 5 99050030 99050030 Bolt, Hex Machine, 5/16"-18 x 5/8" Bolt, Hex Machine, 5/16"-18 x 5/8"
6 6 99050050 99050050 Bolt, Hex Machine, 3/8"-16 x 5/8" Bolt, Hex Machine, 3/8"-16 x 5/8"
7 7 91500050 91500050 Gasket, Volute, .33-2.0HP Gasket, Volute, .33-2.0HP
7 7 91500100 91500100 Gasket, Volute, 3.0HP Gasket, Volute, 3.0HP
8 8 92500050 92500050 Seal, Replacement, #1000 Seal, Replacement, #1000
9 9 91691000 91691000 Impeller, .33 HP Impeller, .33 HP
9 9 91691050 91691050 Impeller, .50 HP Impeller, .50 HP
9 9 91691101 91691101 Impeller, .75 HP Impeller, .75 HP
9 9 91691151 91691151 Impeller, 1.0 HP Impeller, 1.0 HP
9 9 91691201 91691201 Impeller, 1.5 HP Impeller, 1.5 HP
9 9 91691251 91691251 Impeller, 2.0 HP Impeller, 2.0 HP
9 9 91691300 91691300 Impeller, 3.0 HP Impeller, 3.0 HP
10 10 92770050 92770050 Volute, .33-2.0 HP, 1-1/2" Discharge, With Foot Volute, .33-2.0 HP, 1-1/2" Discharge, With Foot
10 10 92770060 92770060 Volute, .33-2.0 HP, 1-1/2" Discharge, Less Foot Volute, .33-2.0 HP, 1-1/2" Discharge, Less Foot
10 10 92770150 92770150 Volute, 3.0 HP Volute, 3.0 HP
10A † 10A 92770200 † 92770200 Volute, .33-2.0 HP, 100% Drain †
11 11 91100100 91100100 Base, Plastic Base, Plastic
12 12 99050110 99050110 Bolt, Hex, Machine, 5/16"-18 x 1" Bolt, Hex, Machine, 5/16"-18 x 1"
13 13 99890050 99890050 Washer, Lock 5/16" Washer, Lock 5/16"
14 14 92290000 92290000 Plug, Pipe Plug, Pipe
15 15 91500150 91500150 Gasket, Trap, 5" Gasket, Trap, 5"
15 15 91500200 91500200 Gasket, Trap, 6" & 8" Gasket, Trap, 6" & 8"
16 16 92620000 92620000 Trap, 5", 1-1/2" Suction Trap, 5", 1-1/2" Suction
16 16 92620050 92620050 Trap, 5", 2" Suction Trap, 5", 2" Suction
16 16 92620100 92620100 Trap, 6", 2" Suction Trap, 6", 2" Suction
17 17 91110000 91110000 Basket, Strainer, 5" (plastic) Basket, Strainer, 5" (plastic)
17 17 91110010 91110010 Basket, Strainer, 6" (plastic) Basket, Strainer, 6" (plastic)
18 18 92200000 92200000 O'ring, Trap Cover, 5", #429 O'ring, Trap Cover, 5", #429
18 18 92200010 92200010 O'ring, Trap Cover, 6", #438 O'ring, Trap Cover, 6", #438
19 19 91230000 91230000 Cover, Trap, 5" Cover, Trap, 5"
19 19 91230050 91230050 Cover, Trap, 6" Cover, Trap, 6"
20 20 91920001 91920001 Lockhandle Lockhandle
21 21 91500250 91500250 Gasket, 100% Drain Gasket, 100% Drain
22 † 22 56910030 † 56910030 Flange, 100% Drain †
23 23 99730050 99730050 Screw, #8-32 x 5/8" Screw, #8-32 x 5/8"
Q Q 91040010 91040010 Assembly, Trap Complete, 5" x 1-1/2" Assembly, Trap Complete, 5" x 1-1/2"
Q Q 91040020 91040020 Assembly, Trap Complete, 5" x 2" Assembly, Trap Complete, 5" x 2"
Q Q 91040030 91040030 Assembly, Trap Complete, 6" x 2" Assembly, Trap Complete, 6" x 2"
† No longer available † No longer available
† † Volute, .33-2.0 HP, 100% Drain †
† † Flange, 100% Drain †
Q Trap Assembly includes Ref. No.'s 5, 14-20
6
