EBARA EBHG - Manual (Page 16)

Ebara Submersible Grinder Sewage Pumps EbG, EbHG
Operation, Installation and Maintenance
Ebara Fluid Handling
www.pumpsebara.com 16
(803) 327-5005 • (803) 327-5097 fax rev. 07/13
Effective Jan. 2013 -
EBG2-2115
REF. NO. DESCRIPTION QTY.
1 Assy, Cord Cap, 30 Ft. Cords 1
2 Screw, Cap, 1/2-13UNC x 1" LG, SST 2
3 Screw, Cap, 5/16-18UNC x 1-3/4" LG, SST 4
4 Bearing, Upper Ball 1
5 O-Ring, Buna-N 4
6 Bearing Plate, Upper, Cast Iron 1
7 Assembly, Housing & Stator 1
8 Assembly, Rotor with Shaft 1
9 Bearing, Lower Ball 1
10 Screw, Cap, 5/16-18UNC x 1-1/4" LG, SST 6
11 Housing, Lower Bearing, Cast Iron 1
12 Seal, Shaft, Lower and Upper, Sil. Carbide 2
13 Ring, Retaining, SST 1
14 Plug, 1/4" NPT pipe, SST 3
15 Screw, Cap, 5/16-18UNC x 1-3/8" LG, SST 4
16 Seal Plate, Lower, Cast Iron 1
17 Screw, Allen HD, 5/16-18UNC x 1" LG, SST 4
18 Volute Case, Cast Iron 1
19 Ring, Square, Buna-N 1
20 Impeller, Cast Iron 1
21 Impeller, Grinding, SST 1
22 Ring, Grinder, SST 1
23 Screw, Allen HD, 1/4-20UNC x 5/8" LG, SST 1
24 Ring, Retainer, SST 1
25 Assembly, Leg, SST/Buna-N 3
26 Nut, Hex, 1/2-13UNC, SST 3
27 O-Ring, Buna-N 1
28 Adapter, 1-1/4" NPT Discharge 1
29 Handle, Lifting, SST 1
30 Relay 1
31 Capacitor, Start, 200mfd, 125vac 1
32 Capacitor, Run, 70mfd, 250vac 1
33 Flange, Grinder ring, Cast iron 1
34 Screw, Cap, 1/4-20UNC x 1" LG, SST 3
