EBARA Fluid Handling 25
PART LIST
Repair Rotating Assembly
ITEM NO. PART NAME QTY PART NUMBER
01 * IMPELLER 01
02 * SEAL PLATE GASKET 01
03 * SEAL ASSEMBLY 01
04 * INBOARD BALL BEARING 01
05 BEARING HOUSE 01
06 PIPE PLUG 01
07 VENTED PLUG 01
08 * OUTBOARD BALL BEARING 01
09 * BRG HOUSING O`RING 01
10 BEARING CAP 01
11 IMPELLER SHAFT 01
12 * SHAFT KEY 01
13 * OUTBOARD OIL SEAL 01
14 BEARING RETAINING RING 01
15 HEX HD CAPSCREW 04
16 LOCKWASHER 04
17 * BEARING HOUSING O’RING 01
18 * INBOARD OIL SEAL 01
19 HEX HD CAPSCREW 04
20 LOCKWASHER 04
21 SEAL PLATE 01
22 * SEAL PLATE O’RING 01
23 IMPELLER WASHER 01
24 IMPELLER CAPSCREW 01
25 SIGHT GAUGE 01
26 PIPE PLUG 01
27 PIPE PLUG 01
28 PIPE PLUG 01
29 SEAL ASSEMBLY O-RING 01
* INDICATES PARTS RECOMMENDED FOR STOCK
