EBARA Submersible Grinder Pumps DGUII/DGFU
Operating, Installation, and Maintenance
EBARA Fluid Handling
www.pumpsebara.com 14
(t) 803 327-5005 • (f) 803 327-5097 rev. 11/05
Leakage Detector
(Does not apply to Model DGUII.)
1. Construction:
Each switch has a magnet-containing float which senses the liquid level and magnetically actuates a dry
reed switch encapsulated within a stem. The switch opens on rise of liquid. Leakage detector should be wired
into control circuit to disconnect power to pump when activated.
2. Specifications
• Apply to 2 to 10HP
Lead Wire
Float Body
(Polypropylene)
Float
(Polypropylene)
Stopper
(316 S.S.)
Open
Close
Breaking Capacity : AC50VA, DC50W
Max. Breaking Current : AC0.5A, DC0.5A
Max. Operating Voltage : AC300V, DC300V
